High Sensitivity Offset Printing Aluminum Plate Ctcp / UV Printing Plate

Name: High Sensitivity Offset Printing Aluminum Plate Ctcp UV Printing Plate
Brand: EcooGraphix
Price: 1 USD

China High Sensitivity Offset Printing Aluminum Plate Ctcp / UV Printing Plate factory

Brand Name : EcooGraphix

Model Number : ECOO-CTCP-D

Certification : CE; ISO

Place of Origin : China

MOQ : 1 SET

Price : Negotiable

Payment Terms : T/T

Delivery Time : 30 DAYS

Packaging Details : Standard Exporting Package

Product Name : Offset Printing Aluminum Plate Ctcp/UV Printing Plate

Plate Type : Positive working, UV sensitive plate

Application : Newspaper, commercial and package printing

Resolution : 1-99% @ 200 LPI

Spectral Sensitivity : 405 nm

Run Length : 200,000 impressions unbaked

Gauges : 0.15, 0.20, 0.25, 0.30, 0.40 (mm)

Shelf Life : 12 Months

Storage and handing : Stored in a cool and dry environment

Contact Now

High Sensitivity Offset Printing Aluminum Plate Ctcp/UV Printing Plate

Model: ECOO-CTCP-D

High Sensitivity Offset Printing Aluminum Plate Ctcp / UV Printing Plate

Product Desription:

Application:
EcooGraphix Positive CTCP Plate(Double Layer) are made for UV based ink. It is also compatible with an ordinary ink. It is use for long run length high grade offset commercial and newspaper printing.

Features:

- Positive writing CTCP (conventional) plate

- Double layers system

- Made with high grade aluminum from Europe

- Wide adaptability for different plate setter brands

- Non-ablative coating

- Run lengths up to 80,000 impressions

- UV Ink up to 50,000 impressions

- Ability to print both AM and FM screening

Advantages:

- Resist UV-ink; workable with both normal ink and UV ink

- Mature product, good stability and wide processing latitude

- Long run length with non-ablative coating

- Being adaptive to most of platesetters, processors and solutions.

Benefits:

-Very Quick turn around time on press

-Robust coating and consistent reliablity

-compatible with most developers

-premium quality of dot reproduction and long run length

High Sensitivity Offset Printing Aluminum Plate Ctcp / UV Printing Plate

Specification:

General Information
Plate Model	ECOO-CTCP-D
Plate Type	Positive CTCP Plate(Double Layer)
Application	High quality commercial and newspaper printing
Substrate	Electro chemically Grained and Anodized lithographic Aluminum
Plate Thickness	0.15,0.20, 0.25,0.30, 0.40 (mm)
Maximum short grain width	Maximum width 1280 mm
Length of Press Runs	Unbaked: 80000 to 100,000 impressions UV INK: About 50,000 impressions
Exposing
Plate setters	Luscher, Basysprint, Cron or EcooGraphix UV series CTCP machine
Exposure energy	50 - 70 mJ/cm²
Spectral Sensitivity	400 - 410 nm - UV Laser
Resolution	2 - 99% LPI 200
Image color	Blue
Developing
Developer	Any Positive plate developer or our own developer
Processing temperature	23°C +/- 2°C
Developing time	25 - 30 sec
Processing Speed	0.80 - 1.20 m/min
Storage and handling
Safelight	Handle under yellow safelight (UV free)
Shelf Life	12 months under recommended storage conditions
Storage and handling	Stored in a cool and dry environment, away from excessive cold, heat and humidity.

High Sensitivity Offset Printing Aluminum Plate Ctcp / UV Printing Plate

FAQ:

Q1: Can I get a sample?
A: We are very glad to provide some sample for you to test. We usually provide 5-15pieces plates for free,but sincerely hope to get your kind support for the air courier freight. This can be returned to you in your first order.

Q2: What is the cost for the CTP plate sample freight?
A: The Air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the Pick-up service from your local agent.

Q3: How long can the sample be ready?
A: It usually takes about 5-7 days to prepare the sample.

Q4: Can I visit your factory?
A: You are warmly welcomed to visit our factory! Our company is in Hangzhou city,which is about 1.5 hour by train from Shanghai.

Q5: How many Square Meters CTP plates can feed one 20' container?
A: About 20000-25000SQM

Q6: Can I take my own brand and label on the packing?
A: Yes, we can provide the OEM with the customer's brand and label.
